Advantages and Features：
1.Compared to traditional high-speed case unpackers with pneumatic systems, the fully mechanical structure of this case unpacker demonstrates greater precision, speed, and stability in its movements.
2.The machine has a small footprint, making it easy to operate, and adjusting for various types of cartons is simpler and more convenient.
3.There is no need to stop the machine to replenish cartons, and the unpacking speed can be adjusted directly on the operation screen without stopping the machine.
4.It solves issues such as misalignment during the folding process of square cartons with vertical case unpackers.
5.The machine does not require a belt to clamp and transport cartons, eliminating the possibility of misalignment caused by asynchrony during belt transportation.
Safety and Alarm：
1.Stop machine when door is opened
2.Automatic early warning reminder to replenish cartons
3.Alarm for unsuccessful carton fetching
4.Alarm for unsuccessful carton formation
Basic Parameters：
Unpacking Method | Horizontal Case Unpacking |
Unpacking Speed | 15-30cartons/min |
Power Rating | 1P/ 220V/750W |
Carton Size(mm) | L240-510*W190-350*H120-350 |
Required Air Pressure | 6kg/cm³ |
Air Consumption | 450NL/min |
Tape Width | 48mm |
Outlet Height | 950mm |
Side Tape Length | 50-60mm |
Feeder Material Storage Height | 880mm |
Machine Weight | 800KG |
Machine Dimensions(mm) | L2320(+100)*W1310(+130)*H1900 |
