Core Competitiveness:
a）Stable, mechanical + servo drive
b）Fast speed, 180 cups/min
c）Strong compatibility, easy to change specifications
d）Professional back-end solution provider
e）European design, high-end atmosphere
Design Concepts:
Safety and protection： Open door stop + safety relay
Efficient ： 180 cups/min
Compatibility ： The number of cups can be adjusted.
Changeable specification ： Box size can be adjusted.
Stabilization ： Servo and mechanical drive
Easy to clean ： Cup conveyor disassembly without tools
High-end and elegant ： European design
Humanized, easy to operate：Object-oriented logic program architecture
Technical Specification：
Type Number | CP30K |
Production capacity/cup | Max.180 cups/min |
Capacity/box | Max.30 boxes/min |
Box Size | Customization |
Electric Voltage | 220v, 60hz, 3phase |
Power Consumption | 6.0KW |
Gas Source | 0.4M3/min，0.6Mpa |
Glue Sprayer | Nordson/United States |
Machine Size | L6627×2390×2020mm |
Weight | 2500KG |
