Product Features：
1.Ultra-high-speed weight sensor imported from Germany, with excellent frequency response.
2.FPGA hardware filter combined with intelligent algorithm, ensuring outstanding weighing processing speed.
3.Intelligent self-learning technology, enabling automatic setting of weighing parameters for easy setup.
4.Ultra-fast dynamic weight tracking and automatic compensation technology, effectively enhancing detection stability.
5.User-friendly operation interface based on full touch screen, making it easy to operate.
6.100 product presets, simplifying product editing and switching.
7.Large-capacity sorting log with data output traceability function.
8.CNC-machined structural components, ensuring excellent dynamic stability.
9.High-quality stainless steel 304 frame, sturdy and durable.
Basic Parameters:
Model/SW | 500-D76 | 600-D76 | 700-D76 | Other Specifications |
Capacity(kg) | 0.01~35 | 0.01~100 | 0.01~100 | See detailed selection catalog for more specifications, or customization is available |
Min Scale(kg) | 0.001 | 0.001 | 0.001 |
Optimal Accuracy(g) | ±5 | ±10 | ±10 |
Max Throughput(pcs/min) | 60 | 40 | 40 |
Parameter Settings | Intelligent Self-Learning |
Weighing Belt Width(mm) | 500 | 600 | 700 |
Weighing Belt Length(mm) | 600/800 | 1200 | 1200 |
Belt Height from Ground(mm) | 700-820/780-900 or customization |
Alarm Mode | Sound and light alarm |
Rejector Type | Push rod/Flap/Belt sagging |
