Bag Type | |
Type of material filled | solid liquid granule powder |
Bag size (W*H) | minsize：100X140 maxsize：210X340 |
Run speed | 80-120 bag/min |
Equipment size (L*W*H) | 4300X1400X2100 |
Bag transfer length | 1200 |
Machine size (L*W*H) | 4300X2800X2100 |
Pocket height | 500-800 |
Motor shafts number | 12 axis Rexroth servo system |
Protection level of | Distribution box IP65 positive pressure seal |
Noise level | 70 |
Total number of stations (number of blanking stations) | 7（2） |
Flexible: Flexible and fast replacement of the product phase, the maximum and minimum size bag type production change time can be completed in a few minutes, the fastest 10 seconds to replace the product phase.
High efficiency: dual station design, full servo control, one device to achieve the capacity of two machines, energy consumption saving 20%.
Module: standardized gas-electric interface; Standardized installation interface; Socket reserve, expansion at any time, flexible change. Station module customization within the free switch to meet different application needs.
Reliable: The whole process closed-loop self-test, before the end product packaging is completed, the possible impact of the intermediate link is finally automatically screened and eliminated, and the operation process is visible on the mobile end.
Minimalist: The complex structure is hidden inside the simple appearance, easy to clean and maintain, and the heating block press cloth is quickly replaced; Buckle tensioning mode, quick replacement; All stainless steel plate seal protection each station surface contact adopts rounded corner transition seal design to avoid sanitary dead corners.
Compact: Flexible scheduling, rotary chain design, installation space reduced by 30%. A new generation of patented bag transfer device, servo on the bag, to ensure the bag efficient and stable.
Certification: CE certification has been completed.
