Rotary Pre-made Bag Counting and Packaging Machine RP8-300/350CW

This equipment is suitable for automatically counting, filling, and sealing small bags such as coffee packs, cereal packs, Isatis root, Xiasangju (a traditional Chinese herbal tea), milk packs, and more. The entire system features a high level of automation, saving labor costs and improving productivity. Speed: up to 30 bags per minute.

Model:
RP8-300/350CW
Brand:
UTMOST

Availability:

Quantity:



Inquire Add to Basket

Fully Mechanical Rotary Pre-made Bag Counting Packaging Machine Automatic Rotary Pre-made Bag Counting Packaging Machine High Speed Rotary Pre-made Bag Counting Packaging Machine High Effiency Rotary Pre-made Bag Counting Packaging Machine High Performance Rotary Pre-made Bag Counting Packaging Machine Rotary Pouch Packer

Product Description

Core Competitiveness:

Easy Specification Change
a) Adjust the handle to accommodate different bag widths.
b) Rotate the button to the desired pocket width for simplicity and convenience.

Performance Features：

a) Easy Specification Change: Quick changeover with just one button.
b) Variable Frequency Speed Control: Uses a variable frequency adjustment device to freely adjust the speed within the specified range
c) Automatic Empty Bag Rejection and Reuse: saves on consumables by automatically rejecting empty bags and allowing for reuse.
d) il-free Vacuum Pump: Avoids contamination of the production environment.
e) Food-grade Materials: All parts in contact with materials are made of 304 stainless stee, complying with food hygiene standards.
f) Easy Cleaning: The machine's tabletop is washable.
9) Simple Operation: PLC control with a user-friendly human-machine interface.
h) Date Printing Adjustment: Easy-to-use knob for adiusting the date printing settings

Technical Parameters：

Model	RP8-300CW	RP8-350CW
Production capacity	30-45Bags/minute	30-40Bags/minute
Packaging container	Zipper stand-up pouch, stand-up pouch, flat pouch (three-side seal, four-side seal, folded edge pouch, etc.)
Container size	W:200X300mm L:200X450mm	W:250-350mm L:≤500mm
Voltage	380v,1ph,50HZ/60HZ
Power consumption	4.0KW	4.0KW
Gas consumption	0.6m³/min	0.6m³/min
Pressure	0.6Mpa	0.6Mpa
Machine size	L3153×2215×1700mm	L3433×2506×1812mm
Weight	2600KG	2900KG

Product Features and Highlights:

High Precision:

The rotary indexing system guarantees precise counting and packaging, ensuring no overfills or underfills.
Perfect for applications that require accurate batch control.

Versatile Packaging:

Can be used for a wide range of products, from small granules to delicate capsules.
Flexible packaging options for different bag sizes.

Automatic Operation:

The fully automated process minimizes human intervention, reducing labor costs and errors.
Integration-ready with other machinery in the production line.

UV & MG Detection:

Built-in UV and MG sensors ensure that each package is correctly sealed and detects foreign objects.
Enhanced product safety and compliance with quality standards.

Space-Efficient Design:

Compact construction allows for easy installation in various factory settings.
Optimized for both small and large-scale production runs.

High-Speed Performance:

Designed for high throughput, increasing productivity while maintaining high-quality output.

Why Choose Us?

Proven Expertise: With years of experience in the packaging industry, we provide machines that are trusted by businesses worldwide.
Custom Solutions: We offer tailored solutions to meet your specific packaging needs, ensuring the machine fits seamlessly into your production environment.
Advanced Technology: Our machines feature cutting-edge technology, including automatic counting, UV and MG detection, and energy-efficient operation.
Superior After-Sales Service: Our dedicated support team is ready to assist with any maintenance or technical issues to ensure minimal downtime.

FAQ

Q1: What materials can the Rotary Counting & Packaging Machine handle?

The machine is suitable for granules, powders, capsules, and other similar products.

Q2: Can the machine be customized for different bag sizes?

Yes, the machine is adjustable and can be configured to handle various pre-made bag sizes.

Q3: Does the machine support integration with other packaging machinery?

Absolutely. It is designed for easy integration into existing production lines to improve overall workflow efficiency.

Q4: How does the UV and MG detection system work?

The UV detection ensures that each package is sealed correctly, while the MG detection checks for any metal contamination, ensuring product quality and safety.

Q5: What are the maintenance requirements for this machine?

Regular cleaning and occasional lubrication are the primary maintenance tasks. Our customer support team provides comprehensive guidance for long-term machine care.
