Product Features：
1.Optimized for vertical packaging and multi-head weighing space, the detection head features a non-metallic zone design.
2.Equipped with a rigid filling technology head, it boasts superior stability, forming the foundation for long-lasting performance.
3.Featuring an anti-interference optoelectronic isolation driver, the operation panel can be installed at a distance.
4.Intelligent learning function enables automatic parameter setting for ease of operation.
5.Utilizes X-R orthogonal decomposition and multiple filtering algorithms for enhanced anti-interference capabilities.
6.Incorporates phase intelligent tracking technology for improved stability.
7.Enhanced detection accuracy through the use of DDS (Direct Digital Synthesis) and digital signal processing technology.
8.Provides metal signal control node outputs for centralized control of packaging machines.
9.Capable of detecting various metal materials including iron, stainless steel, copper, aluminum, and lead.
Product Parameters：
Serial Number | Item | Description |
1 | Detection Aperture(mm) | 50 | 100 | 140 | 200 |
2 | Detection Accuracy(mm) | Fe | 0.4 | 0.6 | 0.8 | 1.0 |
NFe | 0.6 | 0.8 | 1.2 | 1.5 |
Sus | 0.8 | 1.2 | 1.5 | 2.0 |
3 | Installation Space(mm) | 250 | 300 | 450 | 600 |
4 | Product Settings | Intelligent Self-Learning |
5 | Power | 100~220V AC Single-phase，50~60Hz,55W |
