Product Features：
1. It utilizes world-class supplier components, including metal detector heads based on hard-fill technology and high-performance weight scales, coupled with intelligent adaptive algorithms and other technical means, to ensure the detection accuracy and ease of use of the system.
2.The configuration of metal detection and weight detection parameters is integrated into the same product parameterization, allowing operations to be performed within the same interface, thereby reducing the occurrence of operational errors. It possesses a unified intelligent learning algorithm and parameter settings, achieving a true integration of metal detectors and weight scales.
3. It features a unified touch screen for operation and control, offering stability, simplicity, and reliability.
Model/CB | 150(220)-D20 | 220(300)-D28 | 300(360)-D32 | 500 | 600 | Other Specifications |
Capacity(g) | 2~300 | 2~1000 | 5~4000 | 0.02~50kg | 0.05~100kg | See detailed selection catalog for more specifications, or customization is available. |
Min Scale(g) | 0.01 | 0.1 | 0.1 | 1 | 1 | |
Optimal Accuracy(g) | ±0.1 | ±0.3 | ±0.5 | ±5 | ±10 | |
Max Throughput(pcs/min) | 250 | 150 | 100 | 60 | 40 | |
Metal Detection Empty Machine Accuracy(mm) | Depends on the specifications of the metal detector head. | |||||
Weighing Belt Width(mm) | 150(220) | 220(300) | 300(360) | 500 | 600 | |
Weighing Belt Length(mm) | 200/250/300 | 350/450/550 | 450/550/700 | 6800/1300 | 1300 | |
Parameter Settings | Intelligent Self-Learning | |||||
Belt Height from Ground(mm) | 700-820/780-900 or customization | |||||
Alarm Mode | Sound and light alarm | |||||
Rejector Type | Air blow/Push rod/Swing arm/Flap/Belt drop | |||||
Customization：Available
After-sales Service：Provide on-Site Service
Warranty：1 Year
Origin：China
Transport Package：Wooden Case
